PET Laminated Solar Panel Drip Gel Solar Panel ZW-14435.5
Epoxy resin solar panel is made of monocrystalline or polycrystalline silicon. The encapsulation material are made of Epoxy Resin. Characterized by anti-humidity, insulation, excellent transparence and anti-aging, as well as smoothness, no bubble and neat appearance. Hard appearance; long-time life, high-performance to week light; widely used in lamp series, no power source sector.
Description:
A. Epoxy resin encapsulated solar panel.The second type low power solar panel called epoxy resin encapsulated solar panel, which is stuck together by epoxy resin glue at a temperature 50~60 degree, you will see the epoxy coating panel have three layers.Applications: It is more suitable for solar toys, solar educational kits for kids and students in schools.Lifespan: 2 years+
Applications:
1. Resin/Epoxy PCB solar panel,effectively increase waterproof,dustproof,wear resistance,elastic,heat resistance.
2. ETFE and PET PCB surface available,
3. Super light to carry easy anytime, anywhere.
4. High efficiency polycrystalline cells
5. Enviromental friendly AB glue
6. High quality epoxy resin
7. Smooth surface and amazing apprearance
8. Widely used for educational kits,experiment kits,science kits,toys kits,small power supply etc.
9. OEM/ODM/Custom service any size,voltage and color.
Specifications:
| Model: | ZW-9330 |
| Brand: | Zhiwang |
| Size: | 144X35.5X2.5mm |
| Material: | Polycrystalline silicon, epoxy adhesive, PCB |
| Battery: | 18 |
| Peak power: | 0.85W |
| Max voltage: | 9V |
| Max current: | 95MA |
| Open voltage: | 9.9V |
| Short current: | 135MA |
| Weight: | 22g |
| Optimized cell efficiency: | 17%-19% |
| Operating temperature: | -40°C to +85°C |
| NOCT | 48°C+/-2°C |
| Guaranteed | 15 year:90% of its nominal power rating |
| Power Output | 25 yesr:80% of its nominal power rating |
| Warranty Period | Replacement for manufacturing defects within 5 years |
| Certificates | CE, RoHS, FCC, TUV |
| Cells | Monocrystalline silicon Photovoltaic cell |
Competitive Advantage:
• High conversion rate, high efficiency output providing enough power for DIY.
• Solar panel kit with battery power small motors or other loads; perfect devices for science project.
• Portable, compact & stylish size with solid attractive casing.
• UV treated surface and durable weatherproof PCB board.
• This process of solar panels bright surface bright, excellent transmission, light weight, thin thickness.
• Can be used to some DIY solar products, such as solar toys, miniature solar system. Arbitrarily change the output power and voltage through different connect way in series or in parallel, meet your needs!
